Features
Two functions of DC TIG and MMA
Low power consumption and excellent power efficiency can save you money
Be able to be equipped with water-cooling torch.
Application
Pipe welding; Thin sheet fabrication; Special materials such as titanium; Installation; Repair; Maintenance
ACCESSORIES:
TIG torch, electrode holder, earth clamp, welding cable, brush/hammer, protective mask.
| ITEM |
TIGS-160 |
TIGS-180 |
TIGS-250 |
|
Voltage/frequency |
AC220V±10%50Hz/60Hz |
AC220V±10%50Hz/60Hz |
AC380V±10%50Hz/60Hz |
|
Rateinputcapacity(KVA) |
TIG 3.3 |
3.9 |
6.3 |
|
MMA 5.3 |
6.4 |
9.5 |
|
Output current range(A) |
TIG 10-106 |
10-180 |
20-250 |
|
MMA 10-160 |
10-180 |
20-250 |
|
Arc force range(A) |
------ |
------- |
60 |
|
Duty cycle(%) |
60 |
40 |
60 |
|
Output voltage(V) |
TIG 16.4 |
17.2 |
20 |
|
MMA 26.4 |
27.2 |
30 |
|
No-load voltage(V) |
56 |
56 |
54 |
|
Arc starting |
HF |
HF |
HF |
|
Efficiency(%) |
85 |
85 |
85 |
|
Power factor(COSФ) |
0.93 |
0.93 |
0.93 |
|
Blowing time(S) |
2 |
2 |
2 |
|
Net weight(kg) |
8 |
8 |
22 |
|
Cross weight(kg) |
12 |
12 |
26 |
|
Protection class |
IP21 |
IP21 |
IP21 |
|
Insulation class |
B |
B |
B |
|
Dimension(mm) |
371*155*295 |
371*155*295 |
480*205*355 | |
