Features
IGBT module, high efficiency, high power utilization
High welding quality, deep molten pool and strong strength
Less splash, good welding surface, low noise
| ITEM |
ZX7-315 |
ZX7-400 |
ZX7-500 |
ZX7-630 |
|
Power voltage/frequency |
Three phase380v±10%50Hz |
Three phase380v±10%50Hz |
Three phase380v±10%50Hz |
Three phase380v±10%50Hz |
|
Rated output power(KW) |
10.3 |
14.4 |
20 |
27.7 |
|
Rated input current(A) |
21 |
28 |
38 |
52 |
|
Rated duty cycle(%) |
60 |
60 |
60 |
60 |
|
Output current adjustable range(A) |
15-135 |
15-400 |
20-500 |
20-630 |
|
Output no-load voltage(V) |
80±8 |
80±8 |
80±8 |
80±8 |
|
Full load efficiency(%) |
89 |
89 |
89 |
89 |
|
Usable electrodes(mm) |
2-5 |
2-6 |
2-6 |
2-6 |
|
N.w/G.w(kg) |
40/45 |
47/53 |
56/62 |
58/64 |
|
Insulation class |
Main transformer
Power transformer
Output reactance,ect |
Main transformer
Power transformer
Output reactance,ec |
H
B |
H
B |
|
Dimension(mm) |
320*600*630 |
320*600*630 |
335*630*650 |
335*630*650 | |
