Rated voltage of traveling mechanism |
servo motor DC110V
(permanent magnet) |
Wire diameter |
1.0/1.2/1.6/2.0 |
|
Rated current of traveling mechanism |
0.4A |
Applicable wire type |
Solid core flux cored |
|
Rated voltage of wire feeder mechanism |
Print motor
DC18.3V, DC24V |
Rotatable angle of the torch |
±90° |
|
Rated current of wire feeding mechanism |
5A/5.5A |
Torch inclination
(left and right) |
±45° |
|
Type of wire feeding |
Continuous wire feeding |
Torch adjustable distance |
50X60(longitudinalXtransversal),
does not include primary adjustment |
|
Welding speed |
0.2-2.2m/min
0.4-1.5m/min |
Wire spool capacity |
20kg |
|
Wire feeding speed |
1.5-15m/min
2.2-22m/min |
Dimensions(mm) |
480×480×680 |
|
Applicable welding current |
500A |
Weight |
32kg |
